M16 Rear Male Panel Mount 4 Pin Waterproof Connector IP68 Panel
Power Connector
| Model Number | M16 rear panel mount |
|---|
| Connector Type | M16 |
|---|
| Number of Pins | 2 pins, 3 pins~8 pins, 2+3 pins,2+4pins |
|---|
| Material | Nylon PA66 |
|---|
| Applications | For cable to board connection, board to board connection |
|---|
| Mounting Type | Through Hole |
|---|
| Hole Size | Diameter 20.2*19.2mm |
|---|
| Termination | Solder |
|---|
| Type | Rear male panel mount. |
|---|
| IP Level | IP68 |
|---|
| Lifetime | 1500 cycle |
|---|
| Current Resistance | ≤5Ω |
|---|
| Waterproof O-ring | Silicon |
|---|
| Working Temperature | -40℃~105℃ |
|---|
| Contact Material | Brass |
|---|
| Contact Finish | Gold |
|---|
Application
Widely use for outdoor light boxes,IPower equipment,Mining machinery,Construction machinery,ron and Steel production equipment,Ship machinery etc.
Why Choose Us
HYFD has focused on waterproof connectors for over 12 years, we can
provide you with:
● Perfect assembly workshop
● Cable and hardware production
● Independent research and development
● Injection molding and mould making
With us, you can get the best goods in shortest time.
Benefits:
Improve the production process
The connector simplifies the assembly process of electronic
products. It also simplifies the mass production process;
Increase design flexibility
The use of connectors gives engineers greater flexibility when
designing and integrating new products, and when using components
to form systems.
Easy to repair
If an electronic component fails, the failed component can be
quickly replaced when the connector is installed;
FAQ
Q: What is the packing ?
A: Well, we pack it in neutral cartons or as your requirements.
Q: How does your factory control the quality?
A: We have already established a full set of quality control
system. All of our products has been tested twice or even three
times and 100% inspected before delivery out.
Q: What is your terms of payment?
A: T/T full payment in advance for order qty less than 5000 sets.
For order qty over 5000 sets, T/T 30% as deposit, and rest before
delivery.
We'll show you the photos of the products and packages before you
pay the balance.
Q: Do you support OEM, ODM projects?
A: Yes for sure, we can offer OEM/ODM service, we can design the
connectors as per your requirements or drawings and open new
tooling for you.
