Waterproof Quick Conectors IP67 Waterproof Rapid Plug And Socket
Connector With Customized Cable Length
Introduction:
1) Quick lock assembly, simple to use and convenient installation;
2) Integrating current and signal transmission in one of the
multifunctional intergrated circular connector;
3) Nylon firber material greatly improves product durability and
safety;
4) Gold plated brass pins ensure conducting performance stability and
security.
Product characteristics:
1) Waterproof, moisture-proof, rain-proof, sun-proof and
anti-corrosion.
2) Flame retardant, anti-oxidation and environmental protection.
3) Improve the production process: Connectors simplify the assembly
process of electronic products, and also the batch production
process.
4) Easy to maintain: In case of failure, it is not necessary to
clamp the cable, electroplastic sleeve or other parts. Just take
out the two ends of the connector and check, which is very
convenient for maintenance of LED lighting, solar energy and
geothermal energy.
5) Increase design flexibility: Using connectors provides engineers
with greater flexibility in designing and integrating new products,
as well as in composing systems with components.
Application
● Used for LED Strips, LED Wall-washers, LED Underground Light, LED
Rope Light, LED Belt Light, Curtain Light, Twinkle Light and so on.
● Protect from dust and water during immersion, resistant to many
oils and chemicals.
Product Parameters
| Contacts number | 2 | 3 | 4 | 2+3 |
| Rated Voltage | 250V | 250V | 250V | 250V |
| Rated Current | 10A | 10A | 10A | 10A |
| Pin Diameter | 2.35mm | 2.35mm | 2.35mm | 2.35mm |
| Wire Gauge | 2x1.5 mm2 | 3x1.5 mm2 | 4x0.75mm2 | 2x1.0+3x0.5 mm2 |
| Cable diameter | 9.0mm | Work temperature | -40°C~105°C |
| Mechnical life | 1500 plug&unplug times | Pin material | Gold-plated brass |
| Contact resistance | ≤5 mΩ | Waterproof level | IP67 |
| Seal-O-Ring | Silicon rubber | Shell material | Nylon(PA66) |
Packaging Details
1) Carton.
2) Plastic bag.
3) Customized packing as requirement.
Service
We are the original factory of HYFD connectors with the following
advantages:
● Strong production capacity
● Strict quality control system
● Experienced and professional R&D team
We HYFD are a professional manufacturer with over 10 years
experience, we can provide you with:
● Independent research and development.
● Perfect assembly workshop.
● Cable and hardware production.
● Injection molding and mould making.
With us, you can get the best goods in shortest time.
Trade Terms & Delivery Time
Trade terms: EXW
Delivery: 3~5 days for samples, 7-14 days shipment based on the
mass production.
