    IP68 8 Pin Nylon PA66 Waterproof Rj45 Connector

    Ask Lasest Price
    Brand Name : HYFD
    Model Number : RJ45
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10000 Set/Sets per Week
    Delivery Time : 5~12 days as per order quantities
    • Product Details
    • Company Profile

    IP68 8 Pin Nylon PA66 Waterproof Rj45 Connector

    Waterproof RJ45 Connector Outdoor Rated Rj45 Connector 8 Pin Waterproof Cat5e Connectors

    Product Introduction

    1)IP68 waterproof level.

    2)With dust cap,prevent the network parts from moisture,dirt and insects for quality connections.

    3) Quickly insert or pull out.

    4) Ethernet plug in outdoor or waterproof harsh working environment, no need soldering.

    5)Ethernet plug,quick and convenient.
    6)Cat.5e,Cat.6 feed-through coupler,patch cord and assembly.


    Product Parameter

    Connector TypeRJ45
    Number of Pins8 pins
    ApplicationsFor ethernet connection, power, LED, Electronic equipment
    Termination8P ethernet connector
    LockingThread/screw lock
    Waterproof LevelIP67
    Contact Resistance≤5mΩ
    Wire OD7.0mm
    Seal O-ringSilicon
    Temperature-40℃~105℃
    Shell MeterialNylon (PA66)
    Rated Voltage250V
    Rated Current10A
    Contact MaterialBrass
    Contact FinishGold

    Application:

    - Industrial indoor and outdoor event in network environment

    - Live stage action

    - Industrial ethernet in audio, business, amusement

    - DMX lighting

    - Monitoring


    Why Choose Us

    Shenzhen HuaYi-FaDa (HYFD) Technology has focused on waterproof connectors for over 12 years, we can provide you with:

    1.decade of FACTORY production experience.

    2.through a variety of high standards of international certification requirements: such as UL, CE, ROHS.

    3.rapid scale production capacity, only 15 days from mold opening to mass production.

    4.multiple design patents.

    5.cooperation with well-known companies, such as Foxconn, Philips (Signify), OSRAM, Amphenol, Flextronics, etc.


    Service

    ● Perfect assembly workshop

    ● Independent research and development

    ● Injection molding and mould making

    ● Cable and hardware production

    With us, you can get the best goods in shortest time.


    FAQ


    Q: Do you have certification for your connectors?

    A: Yes, most of our connectors have CE/ROHS/IP67/IP68 certificates while some of them

    Q: Do you support OEM, ODM projects?
    A: Yes for sure, we can offer OEM/ODM service, we can design the connectors as per your requirements or drawings and open new tooling for you.


    Q: How does your factory control the quality?
    A: We have already established a full set of quality control system. All of our products has been tested twice or even three times and 100% inspected before delivery out.

    Q: Can I get some samples for testing before further orders?

    A: Certainly, we are happy to offer you samples as per your request. As the old saying goes: To see is to believe, we believe you will be satisfied with our products.
